Rachel A. Altmaier*, Denise E. Hoover, Hannah E. Collins and Joel M. Sarapas*,
{"title":"用点击化学法制备室温固态电池用聚合物-丁二腈电解质","authors":"Rachel A. Altmaier*, Denise E. Hoover, Hannah E. Collins and Joel M. Sarapas*, ","doi":"10.1021/acsaem.5c01134","DOIUrl":null,"url":null,"abstract":"<p >Solid polymer electrolytes offer improved safety over conventional liquid electrolytes but typically suffer from poor conductivity and cyclability. Here, two novel sulfur-containing polymers, cross-linked and block, were designed and synthesized using the thiol–ene click reaction then formulated into solid electrolytes and tested. The cross-linked polymer with succinonitrile and lithium salt incorporated demonstrated conductivity of up to 10<sup>–4</sup> S cm<sup>–1</sup> at 20 °C. The block polymer prepared by the sequential polymerization of a hard and conducting block demonstrated conductivity of up to 10<sup>–5</sup> S cm<sup>–1</sup> at 20 °C when combined with lithium salt. To make a full cell, the block polymer was mixed into the electrode whereas the cross-linked film was used as the combined solid polymer electrolyte and separator layer. At room temperature, the resulting cells achieved 200 cycles at a 0.05 C-rate with 72% capacity retention and over 3000 cycles at a 0.5 C-rate with greater than 90% capacity retention. The high performance of these cells, their ease of fabrication, and the prospects for future performance increases mark a significant advancement toward next-generation solid-state batteries operating at room temperature.</p>","PeriodicalId":4,"journal":{"name":"ACS Applied Energy Materials","volume":"8 17","pages":"12524–12533"},"PeriodicalIF":5.5000,"publicationDate":"2025-08-19","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Polymer-Succinonitrile Electrolytes Prepared through Click Chemistry toward Room-Temperature Solid-State Batteries\",\"authors\":\"Rachel A. Altmaier*, Denise E. Hoover, Hannah E. Collins and Joel M. Sarapas*, \",\"doi\":\"10.1021/acsaem.5c01134\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p >Solid polymer electrolytes offer improved safety over conventional liquid electrolytes but typically suffer from poor conductivity and cyclability. Here, two novel sulfur-containing polymers, cross-linked and block, were designed and synthesized using the thiol–ene click reaction then formulated into solid electrolytes and tested. The cross-linked polymer with succinonitrile and lithium salt incorporated demonstrated conductivity of up to 10<sup>–4</sup> S cm<sup>–1</sup> at 20 °C. The block polymer prepared by the sequential polymerization of a hard and conducting block demonstrated conductivity of up to 10<sup>–5</sup> S cm<sup>–1</sup> at 20 °C when combined with lithium salt. To make a full cell, the block polymer was mixed into the electrode whereas the cross-linked film was used as the combined solid polymer electrolyte and separator layer. At room temperature, the resulting cells achieved 200 cycles at a 0.05 C-rate with 72% capacity retention and over 3000 cycles at a 0.5 C-rate with greater than 90% capacity retention. The high performance of these cells, their ease of fabrication, and the prospects for future performance increases mark a significant advancement toward next-generation solid-state batteries operating at room temperature.</p>\",\"PeriodicalId\":4,\"journal\":{\"name\":\"ACS Applied Energy Materials\",\"volume\":\"8 17\",\"pages\":\"12524–12533\"},\"PeriodicalIF\":5.5000,\"publicationDate\":\"2025-08-19\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"ACS Applied Energy Materials\",\"FirstCategoryId\":\"88\",\"ListUrlMain\":\"https://pubs.acs.org/doi/10.1021/acsaem.5c01134\",\"RegionNum\":3,\"RegionCategory\":\"材料科学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q2\",\"JCRName\":\"CHEMISTRY, PHYSICAL\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"ACS Applied Energy Materials","FirstCategoryId":"88","ListUrlMain":"https://pubs.acs.org/doi/10.1021/acsaem.5c01134","RegionNum":3,"RegionCategory":"材料科学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q2","JCRName":"CHEMISTRY, PHYSICAL","Score":null,"Total":0}
引用次数: 0
摘要
与传统的液体电解质相比,固体聚合物电解质具有更高的安全性,但通常存在导电性和可循环性差的问题。本文设计并合成了两种新型含硫聚合物,交联聚合物和嵌段聚合物,并将其配制成固体电解质并进行了测试。与琥珀腈和锂盐交联的聚合物在20℃时的电导率高达10-4 S cm-1。在与锂盐结合的情况下,在20°C下,由坚硬的导电块序聚制备的嵌段聚合物的电导率高达10-5 S cm-1。为了制造一个完整的电池,将嵌段聚合物混合到电极中,而交联膜用作固体聚合物电解质和隔膜的组合层。在室温下,所得电池在0.05℃的速率下达到200次循环,容量保持率为72%,在0.5℃的速率下达到3000次循环,容量保持率大于90%。这些电池的高性能、易于制造以及未来性能的提高标志着下一代室温下固态电池的重大进步。
Polymer-Succinonitrile Electrolytes Prepared through Click Chemistry toward Room-Temperature Solid-State Batteries
Solid polymer electrolytes offer improved safety over conventional liquid electrolytes but typically suffer from poor conductivity and cyclability. Here, two novel sulfur-containing polymers, cross-linked and block, were designed and synthesized using the thiol–ene click reaction then formulated into solid electrolytes and tested. The cross-linked polymer with succinonitrile and lithium salt incorporated demonstrated conductivity of up to 10–4 S cm–1 at 20 °C. The block polymer prepared by the sequential polymerization of a hard and conducting block demonstrated conductivity of up to 10–5 S cm–1 at 20 °C when combined with lithium salt. To make a full cell, the block polymer was mixed into the electrode whereas the cross-linked film was used as the combined solid polymer electrolyte and separator layer. At room temperature, the resulting cells achieved 200 cycles at a 0.05 C-rate with 72% capacity retention and over 3000 cycles at a 0.5 C-rate with greater than 90% capacity retention. The high performance of these cells, their ease of fabrication, and the prospects for future performance increases mark a significant advancement toward next-generation solid-state batteries operating at room temperature.
