[多孔材料吸附剂在环境和食品样品中农药残留提取中的最新应用]。

Qi-Tong Xu, Meng Yu, Chang Xie, Yan Cao, Su-Rong Mei
{"title":"[多孔材料吸附剂在环境和食品样品中农药残留提取中的最新应用]。","authors":"Qi-Tong Xu, Meng Yu, Chang Xie, Yan Cao, Su-Rong Mei","doi":"10.3724/SP.J.1123.2024.12009","DOIUrl":null,"url":null,"abstract":"<p><p>Pesticides are ubiquitous to human life but their residues are indispensable micropollutants that threaten human health. In recent years, the global use of pesticides has increased significantly in recent years, and their environmental profiles have become increasingly complex as different generations of pesticides have appeared on the market. The residues of various legacy and emerging pesticides are omnipresent in both the environment and food medias. Consequently, developing rapid and sensitive detection technologies for analyzing multiple residues is imperative. Sample pretreatment, particularly adsorbent selection and innovation, is indispensable in this regard. So far, a wide range of hybrid nanomaterials have been used for the enrichment or adsorption of pesticide residues. While traditional solid-phase-extraction-based (SPE-based) sorbents are widely used, they lack specific interactions and are poorly selective. Normal carbon materials (e.g., graphene oxide and carbon nanotubes), which have large surface areas and pore volumes, have progressed significantly; however, they still have insufficient active adsorption sites. Notably, porous materials, including metal-organic frameworks (MOFs), porous organic polymers (POPs) (including covalent organic frameworks (COFs), covalent triazine frameworks (CTFs), conjugated microporous polymers (CMPs), microporous organic networks (MONs, sub-familied by CMPs, porous aromatic frameworks (PAFs), and hyper-crosslinked polymers (HCPs)), nano-porous carbons(NPCs), and zeolites display exceptional properties because they have high porosity, tunable pore sizes, large surface areas, and diverse modification sites. In this review, strategies for the enhancement of adsorption performance of porous-material-based adsorbents, including materials hybridization, monomer modification, configuration regulation, and properties adjustment are first introduced. Furthermore, publications from 2018 to 2024 pertaining to the utilization of porous-material-based adsorbents for diverse types of pesticides were briefly elaborated. The properties of pesticides, the designs and performance of porous materials, and their interaction mechanisms were discussed. A total of 14 types of pesticides are included in the discussion, namely organochlorine pesticides (OCPs), organophosphorus pesticides (OPPs), pyrethroids (PYRs), benzoylurea insecticides (BUs), neonicotinoid insecticides (NEOs), phenyl-pyrazole insecticides (PPZs), phenoxy carboxylic acid herbicides (PCAs), triazine herbicides (TRZHs), benzimidazole fungicides (BZDs), azole/triazoles fungicides, strobilurin fungicides (SFs), carbamate insecticides (Carbs), phenyl-urea herbicides (PUHs), and diamide insecticides. Our summary revealed that an adsorbent was predominantly designed based on the textural properties of the target pesticide and the structural characteristics of the hybrid material, such as its functional groups, polarity, and pore size, to enhance adsorption performance and selectivity. MOFs and POPs are the most commonly used pesticide adsorbents, whereas fewer NPCs have been reported in this regard. Additionally, the applications potentials of porous-material-based adsorbents were explored. The findings revealed that conventional pesticides, such as OPPs, have been significantly researched in the extraction technology field. In contrast, concerns surrounding newer pesticides, including NEOs, PPZs, and SFs, as well as some significantly detected residues (BZDs and TRZHs), have not been fully addressed, highlighting the need for future adsorbent research that prioritizes emerging and significantly detected pesticides.</p>","PeriodicalId":101336,"journal":{"name":"Se pu = Chinese journal of chromatography","volume":"43 7","pages":"713-725"},"PeriodicalIF":0.0000,"publicationDate":"2025-07-01","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC12231466/pdf/","citationCount":"0","resultStr":"{\"title\":\"[Recent applications of porous-material-based adsorbents for extracting pesticide residues from environmental and foodstuff samples].\",\"authors\":\"Qi-Tong Xu, Meng Yu, Chang Xie, Yan Cao, Su-Rong Mei\",\"doi\":\"10.3724/SP.J.1123.2024.12009\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p><p>Pesticides are ubiquitous to human life but their residues are indispensable micropollutants that threaten human health. In recent years, the global use of pesticides has increased significantly in recent years, and their environmental profiles have become increasingly complex as different generations of pesticides have appeared on the market. The residues of various legacy and emerging pesticides are omnipresent in both the environment and food medias. Consequently, developing rapid and sensitive detection technologies for analyzing multiple residues is imperative. Sample pretreatment, particularly adsorbent selection and innovation, is indispensable in this regard. So far, a wide range of hybrid nanomaterials have been used for the enrichment or adsorption of pesticide residues. While traditional solid-phase-extraction-based (SPE-based) sorbents are widely used, they lack specific interactions and are poorly selective. Normal carbon materials (e.g., graphene oxide and carbon nanotubes), which have large surface areas and pore volumes, have progressed significantly; however, they still have insufficient active adsorption sites. Notably, porous materials, including metal-organic frameworks (MOFs), porous organic polymers (POPs) (including covalent organic frameworks (COFs), covalent triazine frameworks (CTFs), conjugated microporous polymers (CMPs), microporous organic networks (MONs, sub-familied by CMPs, porous aromatic frameworks (PAFs), and hyper-crosslinked polymers (HCPs)), nano-porous carbons(NPCs), and zeolites display exceptional properties because they have high porosity, tunable pore sizes, large surface areas, and diverse modification sites. In this review, strategies for the enhancement of adsorption performance of porous-material-based adsorbents, including materials hybridization, monomer modification, configuration regulation, and properties adjustment are first introduced. Furthermore, publications from 2018 to 2024 pertaining to the utilization of porous-material-based adsorbents for diverse types of pesticides were briefly elaborated. The properties of pesticides, the designs and performance of porous materials, and their interaction mechanisms were discussed. A total of 14 types of pesticides are included in the discussion, namely organochlorine pesticides (OCPs), organophosphorus pesticides (OPPs), pyrethroids (PYRs), benzoylurea insecticides (BUs), neonicotinoid insecticides (NEOs), phenyl-pyrazole insecticides (PPZs), phenoxy carboxylic acid herbicides (PCAs), triazine herbicides (TRZHs), benzimidazole fungicides (BZDs), azole/triazoles fungicides, strobilurin fungicides (SFs), carbamate insecticides (Carbs), phenyl-urea herbicides (PUHs), and diamide insecticides. Our summary revealed that an adsorbent was predominantly designed based on the textural properties of the target pesticide and the structural characteristics of the hybrid material, such as its functional groups, polarity, and pore size, to enhance adsorption performance and selectivity. MOFs and POPs are the most commonly used pesticide adsorbents, whereas fewer NPCs have been reported in this regard. Additionally, the applications potentials of porous-material-based adsorbents were explored. The findings revealed that conventional pesticides, such as OPPs, have been significantly researched in the extraction technology field. In contrast, concerns surrounding newer pesticides, including NEOs, PPZs, and SFs, as well as some significantly detected residues (BZDs and TRZHs), have not been fully addressed, highlighting the need for future adsorbent research that prioritizes emerging and significantly detected pesticides.</p>\",\"PeriodicalId\":101336,\"journal\":{\"name\":\"Se pu = Chinese journal of chromatography\",\"volume\":\"43 7\",\"pages\":\"713-725\"},\"PeriodicalIF\":0.0000,\"publicationDate\":\"2025-07-01\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC12231466/pdf/\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Se pu = Chinese journal of chromatography\",\"FirstCategoryId\":\"1085\",\"ListUrlMain\":\"https://doi.org/10.3724/SP.J.1123.2024.12009\",\"RegionNum\":0,\"RegionCategory\":null,\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"\",\"JCRName\":\"\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Se pu = Chinese journal of chromatography","FirstCategoryId":"1085","ListUrlMain":"https://doi.org/10.3724/SP.J.1123.2024.12009","RegionNum":0,"RegionCategory":null,"ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"","JCRName":"","Score":null,"Total":0}
引用次数: 0

摘要

农药在人类生活中无处不在,但农药残留是危害人类健康不可缺少的微量污染物。近年来,全球农药使用量大幅增加,随着不同代农药的出现,农药的环境概况也变得越来越复杂。各种遗留和新兴农药的残留在环境和食品介质中无处不在。因此,开发快速、灵敏的多残留检测技术势在必行。在这方面,样品预处理,特别是吸附剂的选择和创新是必不可少的。目前,各种杂化纳米材料已广泛应用于农药残留的富集或吸附。虽然传统的固相萃取吸附剂被广泛使用,但它们缺乏特定的相互作用,选择性差。普通的碳材料(如氧化石墨烯和碳纳米管)具有较大的表面积和孔隙体积,已经取得了很大的进展,但它们的活性吸附位点仍然不足。值得注意的是,多孔材料,包括金属有机框架(MOFs)、多孔有机聚合物(POPs)(包括共价有机框架(COFs)、共价三嗪框架(CTFs)、共轭微孔聚合物(cmp)、微孔有机网络(MONs, cmp亚族、多孔芳香框架(PAFs)和超交联聚合物(HCPs))、纳米多孔碳(npc)和沸石,由于它们具有高孔隙率、可调孔径、表面积大,修饰位点多样。本文首先介绍了提高多孔材料吸附剂吸附性能的策略,包括材料杂化、单体改性、构型调节和性能调整。此外,简要阐述了2018年至2024年有关多孔材料吸附剂在不同类型农药中的应用的出版物。讨论了农药的性质、多孔材料的设计和性能以及它们的相互作用机理。共涉及14种农药,即有机氯农药(OCPs)、有机磷农药(OPPs)、拟除虫菊酯(PYRs)、苯甲酰脲类杀虫剂(BUs)、新烟碱类杀虫剂(NEOs)、苯基吡唑类杀虫剂(PPZs)、苯氧羧酸类除草剂(PCAs)、三嗪类除草剂(trzs)、苯并咪唑类杀菌剂(BZDs)、唑/三唑类杀菌剂、strobilurin类杀菌剂(SFs)、氨基甲酸酯类杀虫剂(碳水化合物)、苯基脲类除草剂(PUHs)、二胺类杀虫剂。我们的总结表明,主要基于目标农药的结构特性和杂化材料的结构特征(如其官能团、极性和孔径)来设计吸附剂,以提高吸附性能和选择性。MOFs和持久性有机污染物是最常用的农药吸附剂,而在这方面报告的非持久性有机污染物较少。展望了多孔材料基吸附剂的应用前景。研究结果表明,传统农药,如有机磷农药,在提取技术领域已经得到了大量的研究。相比之下,对新农药,包括neo, ppz和sf以及一些显著检测到的残留物(BZDs和trzs)的担忧尚未得到充分解决,这突出了未来吸附剂研究的必要性,优先考虑新兴和显著检测到的农药。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

[Recent applications of porous-material-based adsorbents for extracting pesticide residues from environmental and foodstuff samples].

[Recent applications of porous-material-based adsorbents for extracting pesticide residues from environmental and foodstuff samples].

[Recent applications of porous-material-based adsorbents for extracting pesticide residues from environmental and foodstuff samples].

[Recent applications of porous-material-based adsorbents for extracting pesticide residues from environmental and foodstuff samples].

Pesticides are ubiquitous to human life but their residues are indispensable micropollutants that threaten human health. In recent years, the global use of pesticides has increased significantly in recent years, and their environmental profiles have become increasingly complex as different generations of pesticides have appeared on the market. The residues of various legacy and emerging pesticides are omnipresent in both the environment and food medias. Consequently, developing rapid and sensitive detection technologies for analyzing multiple residues is imperative. Sample pretreatment, particularly adsorbent selection and innovation, is indispensable in this regard. So far, a wide range of hybrid nanomaterials have been used for the enrichment or adsorption of pesticide residues. While traditional solid-phase-extraction-based (SPE-based) sorbents are widely used, they lack specific interactions and are poorly selective. Normal carbon materials (e.g., graphene oxide and carbon nanotubes), which have large surface areas and pore volumes, have progressed significantly; however, they still have insufficient active adsorption sites. Notably, porous materials, including metal-organic frameworks (MOFs), porous organic polymers (POPs) (including covalent organic frameworks (COFs), covalent triazine frameworks (CTFs), conjugated microporous polymers (CMPs), microporous organic networks (MONs, sub-familied by CMPs, porous aromatic frameworks (PAFs), and hyper-crosslinked polymers (HCPs)), nano-porous carbons(NPCs), and zeolites display exceptional properties because they have high porosity, tunable pore sizes, large surface areas, and diverse modification sites. In this review, strategies for the enhancement of adsorption performance of porous-material-based adsorbents, including materials hybridization, monomer modification, configuration regulation, and properties adjustment are first introduced. Furthermore, publications from 2018 to 2024 pertaining to the utilization of porous-material-based adsorbents for diverse types of pesticides were briefly elaborated. The properties of pesticides, the designs and performance of porous materials, and their interaction mechanisms were discussed. A total of 14 types of pesticides are included in the discussion, namely organochlorine pesticides (OCPs), organophosphorus pesticides (OPPs), pyrethroids (PYRs), benzoylurea insecticides (BUs), neonicotinoid insecticides (NEOs), phenyl-pyrazole insecticides (PPZs), phenoxy carboxylic acid herbicides (PCAs), triazine herbicides (TRZHs), benzimidazole fungicides (BZDs), azole/triazoles fungicides, strobilurin fungicides (SFs), carbamate insecticides (Carbs), phenyl-urea herbicides (PUHs), and diamide insecticides. Our summary revealed that an adsorbent was predominantly designed based on the textural properties of the target pesticide and the structural characteristics of the hybrid material, such as its functional groups, polarity, and pore size, to enhance adsorption performance and selectivity. MOFs and POPs are the most commonly used pesticide adsorbents, whereas fewer NPCs have been reported in this regard. Additionally, the applications potentials of porous-material-based adsorbents were explored. The findings revealed that conventional pesticides, such as OPPs, have been significantly researched in the extraction technology field. In contrast, concerns surrounding newer pesticides, including NEOs, PPZs, and SFs, as well as some significantly detected residues (BZDs and TRZHs), have not been fully addressed, highlighting the need for future adsorbent research that prioritizes emerging and significantly detected pesticides.
