原位锚定在MXene上的Co掺杂NiFe LDH纳米片用于水裂解中高效的析氧反应

IF 2.6 3区 化学 Q2 CHEMISTRY, MULTIDISCIPLINARY
CrystEngComm Pub Date : 2025-05-15 DOI:10.1039/D5CE00430F
Wenping Dong, Bo Wei, Lifang Zhang, Zhe Zhang, Hongyu Yang, Yixuan Zhou, Xiaojun Pan, Xin Xia, Feng Ye and Chao Xu
{"title":"原位锚定在MXene上的Co掺杂NiFe LDH纳米片用于水裂解中高效的析氧反应","authors":"Wenping Dong, Bo Wei, Lifang Zhang, Zhe Zhang, Hongyu Yang, Yixuan Zhou, Xiaojun Pan, Xin Xia, Feng Ye and Chao Xu","doi":"10.1039/D5CE00430F","DOIUrl":null,"url":null,"abstract":"<p >The development of efficient, low-cost, and long-lasting electrocatalysts is critical for enhancing the oxygen evolution reaction (OER) in alkaline water splitting. Herein, we successfully synthesized a novel MXene (Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small>) supported Co-doped NiFe layered double hydroxide (NiFeCo<small><sub>0.75</sub></small> LDH@Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small>) by the simple solvothermal method. The morphology of NiFeCo<small><sub>0.75</sub></small> LDH@Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small> was characterized using scanning electron microscopy. The electrocatalytic performance of NiFeCo<small><sub>0.75</sub></small> LDH@Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small> was measured by linear sweep voltammetry. The NiFeCo<small><sub>0.75</sub></small> LDH@Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small> catalyst exhibited superior OER activity with the uniform dispersion of NiFeCo<small><sub>0.75</sub></small> LDH nanosheets uniformly dispersed on the Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small> support. The overpotential of NiFeCo<small><sub>0.75</sub></small> LDH@Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small> at current densities of 10 and 300 mA cm<small><sup>−2</sup></small> is only 258 and 330 mV, respectively, which is significantly lower than those of NiFeCo<small><sub>0.75</sub></small> LDH (259 mV and 351 mV) and NiFe LDH (270 mV and 374 mV), respectively. Additionally, the NiFeCo<small><sub>0.75</sub></small> LDH@Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small> catalyst achieved a Tafel slope of 44.78 mV dec<small><sup>−1</sup></small> and demonstrated excellent long-term stability for over 400 h at 10 mA cm<small><sup>−2</sup></small>. Furthermore, the OER catalytic mechanism of Co doped NiFe LDH@Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small> was preliminarily discussed. The results show that the MXene support and Co doping effectively tailors the electronic structure and D-band center of LDH, thereby boosting the OER performance of NiFeCo<small><sub>0.75</sub></small> LDH@Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small>.</p>","PeriodicalId":70,"journal":{"name":"CrystEngComm","volume":" 24","pages":" 4147-4159"},"PeriodicalIF":2.6000,"publicationDate":"2025-05-15","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Co doped NiFe LDH nanosheets in situ anchored on MXene for the highly efficient oxygen evolution reaction in water splitting†\",\"authors\":\"Wenping Dong, Bo Wei, Lifang Zhang, Zhe Zhang, Hongyu Yang, Yixuan Zhou, Xiaojun Pan, Xin Xia, Feng Ye and Chao Xu\",\"doi\":\"10.1039/D5CE00430F\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p >The development of efficient, low-cost, and long-lasting electrocatalysts is critical for enhancing the oxygen evolution reaction (OER) in alkaline water splitting. Herein, we successfully synthesized a novel MXene (Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small>) supported Co-doped NiFe layered double hydroxide (NiFeCo<small><sub>0.75</sub></small> LDH@Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small>) by the simple solvothermal method. The morphology of NiFeCo<small><sub>0.75</sub></small> LDH@Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small> was characterized using scanning electron microscopy. The electrocatalytic performance of NiFeCo<small><sub>0.75</sub></small> LDH@Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small> was measured by linear sweep voltammetry. The NiFeCo<small><sub>0.75</sub></small> LDH@Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small> catalyst exhibited superior OER activity with the uniform dispersion of NiFeCo<small><sub>0.75</sub></small> LDH nanosheets uniformly dispersed on the Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small> support. The overpotential of NiFeCo<small><sub>0.75</sub></small> LDH@Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small> at current densities of 10 and 300 mA cm<small><sup>−2</sup></small> is only 258 and 330 mV, respectively, which is significantly lower than those of NiFeCo<small><sub>0.75</sub></small> LDH (259 mV and 351 mV) and NiFe LDH (270 mV and 374 mV), respectively. Additionally, the NiFeCo<small><sub>0.75</sub></small> LDH@Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small> catalyst achieved a Tafel slope of 44.78 mV dec<small><sup>−1</sup></small> and demonstrated excellent long-term stability for over 400 h at 10 mA cm<small><sup>−2</sup></small>. Furthermore, the OER catalytic mechanism of Co doped NiFe LDH@Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small> was preliminarily discussed. The results show that the MXene support and Co doping effectively tailors the electronic structure and D-band center of LDH, thereby boosting the OER performance of NiFeCo<small><sub>0.75</sub></small> LDH@Ti<small><sub>3</sub></small>C<small><sub>2</sub></small>T<small><sub><em>x</em></sub></small>.</p>\",\"PeriodicalId\":70,\"journal\":{\"name\":\"CrystEngComm\",\"volume\":\" 24\",\"pages\":\" 4147-4159\"},\"PeriodicalIF\":2.6000,\"publicationDate\":\"2025-05-15\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"CrystEngComm\",\"FirstCategoryId\":\"92\",\"ListUrlMain\":\"https://pubs.rsc.org/en/content/articlelanding/2025/ce/d5ce00430f\",\"RegionNum\":3,\"RegionCategory\":\"化学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q2\",\"JCRName\":\"CHEMISTRY, MULTIDISCIPLINARY\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"CrystEngComm","FirstCategoryId":"92","ListUrlMain":"https://pubs.rsc.org/en/content/articlelanding/2025/ce/d5ce00430f","RegionNum":3,"RegionCategory":"化学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q2","JCRName":"CHEMISTRY, MULTIDISCIPLINARY","Score":null,"Total":0}
引用次数: 0

摘要

开发高效、低成本、长效的电催化剂是提高碱水裂解过程中析氧反应的关键。本文采用简单的溶剂热法成功合成了一种新型的MXene (Ti3C2Tx)负载的共掺杂NiFe层状双氢氧化物(NiFeCo0.75 LDH@Ti3C2Tx)。利用扫描电镜对NiFeCo0.75 LDH@Ti3C2Tx的形貌进行表征。采用线性扫描伏安法测定了NiFeCo0.75 LDH@Ti3C2Tx的电催化性能。NiFeCo0.75 LDH@Ti3C2Tx催化剂表现出优异的OER活性,NiFeCo0.75 LDH纳米片均匀分散在Ti3C2Tx载体上。NiFeCo0.75 LDH@Ti3C2Tx在10和300 mA cm−2电流密度下的过电位分别为258和330 mV,明显低于NiFeCo0.75 LDH (259 mV和351 mV)和NiFe LDH (270 mV和374 mV)。此外,NiFeCo0.75 LDH@Ti3C2Tx催化剂的Tafel斜率为44.78 mV dec−1,并在10 mA cm−2下表现出超过400小时的优异长期稳定性。并对Co掺杂NiFe LDH@Ti3C2Tx的OER催化机理进行了初步探讨。结果表明,MXene载体和Co掺杂有效地调整了LDH的电子结构和d带中心,从而提高了NiFeCo0.75的OER性能LDH@Ti3C2Tx。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

Co doped NiFe LDH nanosheets in situ anchored on MXene for the highly efficient oxygen evolution reaction in water splitting†

Co doped NiFe LDH nanosheets in situ anchored on MXene for the highly efficient oxygen evolution reaction in water splitting†

The development of efficient, low-cost, and long-lasting electrocatalysts is critical for enhancing the oxygen evolution reaction (OER) in alkaline water splitting. Herein, we successfully synthesized a novel MXene (Ti3C2Tx) supported Co-doped NiFe layered double hydroxide (NiFeCo0.75 LDH@Ti3C2Tx) by the simple solvothermal method. The morphology of NiFeCo0.75 LDH@Ti3C2Tx was characterized using scanning electron microscopy. The electrocatalytic performance of NiFeCo0.75 LDH@Ti3C2Tx was measured by linear sweep voltammetry. The NiFeCo0.75 LDH@Ti3C2Tx catalyst exhibited superior OER activity with the uniform dispersion of NiFeCo0.75 LDH nanosheets uniformly dispersed on the Ti3C2Tx support. The overpotential of NiFeCo0.75 LDH@Ti3C2Tx at current densities of 10 and 300 mA cm−2 is only 258 and 330 mV, respectively, which is significantly lower than those of NiFeCo0.75 LDH (259 mV and 351 mV) and NiFe LDH (270 mV and 374 mV), respectively. Additionally, the NiFeCo0.75 LDH@Ti3C2Tx catalyst achieved a Tafel slope of 44.78 mV dec−1 and demonstrated excellent long-term stability for over 400 h at 10 mA cm−2. Furthermore, the OER catalytic mechanism of Co doped NiFe LDH@Ti3C2Tx was preliminarily discussed. The results show that the MXene support and Co doping effectively tailors the electronic structure and D-band center of LDH, thereby boosting the OER performance of NiFeCo0.75 LDH@Ti3C2Tx.
