An automated bandwidth division for the LHCb upgrade trigger.
The upgraded Large Hadron Collider beauty (LHCb) experiment is the first detector based at a hadron collider using a fully software-based trigger. The first 'High Level Trigger' stage (HLT1) reduces the event rate from 30 MHz to approximately 1 MHz based on reconstruction criteria from the tracking system, and consists of trigger selections implemented on Graphics Processing Units (GPUs). These selections are further refined following the full offline-quality reconstruction at the second stage (HLT2) prior to saving for analysis. An automated bandwidth division has been performed to equitably divide this 1 MHz HLT1 Output Rate (OR) between the signals of interest to the LHCb physics program. This was achieved by optimizing a set of trigger selections that maximize efficiency for signals of interest to LHCb while keeping the total HLT1 readout capped to a maximum. The bandwidth division tool has been used to determine the optimal selection for 35 selection algorithms over 80 characteristic physics channels.
