术中计算机断层扫描引导下的新型微创颈椎椎弓根螺钉固定系统。

Q1 Medicine
Journal of spine surgery Pub Date : 2025-03-24 Epub Date: 2024-12-16 DOI:10.21037/jss-24-45
Christian Blume, Tobias Philip Schmidt, Christian-Andreas Mueller, Alexander Romagna, Miguel Pishnamaz, Hans Clusmann, Ulf Bertram
{"title":"术中计算机断层扫描引导下的新型微创颈椎椎弓根螺钉固定系统。","authors":"Christian Blume, Tobias Philip Schmidt, Christian-Andreas Mueller, Alexander Romagna, Miguel Pishnamaz, Hans Clusmann, Ulf Bertram","doi":"10.21037/jss-24-45","DOIUrl":null,"url":null,"abstract":"<p><strong>Background: </strong>Since its introduction, placement of cervical pedicle screws (CPS) has been considered a procedure with a very high-risk profile. Minimally invasive CPS placement was not even considered at all. However, as surgical techniques and image guided intra-operative navigation have been refined over the last decade, navigated CPS placement has become a standard procedure in well-established spine centers. Currently, the first off-the-shelf percutaneous CPS placement platforms are becoming available. The aim of this study is to assess feasibility and accuracy of an minimally invasive surgery (MIS) CPS fixation system in a pilot series.</p><p><strong>Methods: </strong>Between January and July 2023, we treated a cohort of ten patients using a new cervical MIS platform. Forty pedicle screws were inserted percutaneously in the c-spine using intra-operative computed tomography (CT) guided navigation and retrospectively analysed for accuracy using a modified Gertzbein & Robbins (G&R) classification. Adverse events and other patient-related data were also documented.</p><p><strong>Results: </strong>Ninety percent of all screws were placed accurately (80% on perfect trajectory, 10% showed minor perforations). Another 10% (four screws) caused pedicle wall breaches between 2 and 4 mm, but were not revised, since misplacement was not associated with neurological deficit or inferior biomechanics. One patient experienced neurological deterioration, but not associated with screw misplacement. The transverse foramen was breached twice, however not endangering the vertebral arteries.</p><p><strong>Conclusions: </strong>In this pilot series MIS CPS placement yielded accurate placement rates comparable to open surgical approaches reported in the literature. Hence, MIS CPS placement appears to be a feasible and safe procedure in selected cases.</p>","PeriodicalId":17131,"journal":{"name":"Journal of spine surgery","volume":"11 1","pages":"96-103"},"PeriodicalIF":0.0000,"publicationDate":"2025-03-24","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11998035/pdf/","citationCount":"0","resultStr":"{\"title\":\"A new minimally invasive cervical pedicle screw (CPS) fixation system using intra-operative computed tomography-guided navigation.\",\"authors\":\"Christian Blume, Tobias Philip Schmidt, Christian-Andreas Mueller, Alexander Romagna, Miguel Pishnamaz, Hans Clusmann, Ulf Bertram\",\"doi\":\"10.21037/jss-24-45\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p><strong>Background: </strong>Since its introduction, placement of cervical pedicle screws (CPS) has been considered a procedure with a very high-risk profile. Minimally invasive CPS placement was not even considered at all. However, as surgical techniques and image guided intra-operative navigation have been refined over the last decade, navigated CPS placement has become a standard procedure in well-established spine centers. Currently, the first off-the-shelf percutaneous CPS placement platforms are becoming available. The aim of this study is to assess feasibility and accuracy of an minimally invasive surgery (MIS) CPS fixation system in a pilot series.</p><p><strong>Methods: </strong>Between January and July 2023, we treated a cohort of ten patients using a new cervical MIS platform. Forty pedicle screws were inserted percutaneously in the c-spine using intra-operative computed tomography (CT) guided navigation and retrospectively analysed for accuracy using a modified Gertzbein & Robbins (G&R) classification. Adverse events and other patient-related data were also documented.</p><p><strong>Results: </strong>Ninety percent of all screws were placed accurately (80% on perfect trajectory, 10% showed minor perforations). Another 10% (four screws) caused pedicle wall breaches between 2 and 4 mm, but were not revised, since misplacement was not associated with neurological deficit or inferior biomechanics. One patient experienced neurological deterioration, but not associated with screw misplacement. The transverse foramen was breached twice, however not endangering the vertebral arteries.</p><p><strong>Conclusions: </strong>In this pilot series MIS CPS placement yielded accurate placement rates comparable to open surgical approaches reported in the literature. Hence, MIS CPS placement appears to be a feasible and safe procedure in selected cases.</p>\",\"PeriodicalId\":17131,\"journal\":{\"name\":\"Journal of spine surgery\",\"volume\":\"11 1\",\"pages\":\"96-103\"},\"PeriodicalIF\":0.0000,\"publicationDate\":\"2025-03-24\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11998035/pdf/\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Journal of spine surgery\",\"FirstCategoryId\":\"1085\",\"ListUrlMain\":\"https://doi.org/10.21037/jss-24-45\",\"RegionNum\":0,\"RegionCategory\":null,\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"2024/12/16 0:00:00\",\"PubModel\":\"Epub\",\"JCR\":\"Q1\",\"JCRName\":\"Medicine\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Journal of spine surgery","FirstCategoryId":"1085","ListUrlMain":"https://doi.org/10.21037/jss-24-45","RegionNum":0,"RegionCategory":null,"ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"2024/12/16 0:00:00","PubModel":"Epub","JCR":"Q1","JCRName":"Medicine","Score":null,"Total":0}
引用次数: 0

摘要

背景:自引入以来,颈椎椎弓根螺钉(CPS)的放置一直被认为是一种非常高风险的手术。甚至根本没有考虑微创CPS放置。然而,随着手术技术和图像引导术中导航在过去十年中不断完善,导航CPS放置已成为成熟脊柱中心的标准程序。目前,第一个现成的经皮CPS放置平台正在变得可用。本研究的目的是评估微创手术(MIS) CPS固定系统在试点系列中的可行性和准确性。方法:在2023年1月至7月期间,我们使用新的宫颈MIS平台治疗了10例患者。采用术中计算机断层扫描(CT)引导导航,经皮将40枚椎弓根螺钉置入颈椎,并采用改进的Gertzbein & Robbins (G&R)分类回顾性分析其准确性。不良事件和其他与患者相关的数据也被记录下来。结果:90%的螺钉放置准确(80%轨迹完美,10%出现轻微穿孔)。另外10%(4颗螺钉)导致椎弓根壁破裂2 - 4mm,但没有进行翻修,因为错位与神经功能缺损或生物力学性能较差无关。1例患者出现神经功能恶化,但与螺钉错位无关。横孔破裂两次,但未危及椎动脉。结论:在这个试点系列中,MIS CPS放置的准确放置率与文献报道的开放手术入路相当。因此,MIS CPS安置似乎是一个可行的和安全的程序,在选定的情况下。
本文章由计算机程序翻译,如有差异,请以英文原文为准。
A new minimally invasive cervical pedicle screw (CPS) fixation system using intra-operative computed tomography-guided navigation.

Background: Since its introduction, placement of cervical pedicle screws (CPS) has been considered a procedure with a very high-risk profile. Minimally invasive CPS placement was not even considered at all. However, as surgical techniques and image guided intra-operative navigation have been refined over the last decade, navigated CPS placement has become a standard procedure in well-established spine centers. Currently, the first off-the-shelf percutaneous CPS placement platforms are becoming available. The aim of this study is to assess feasibility and accuracy of an minimally invasive surgery (MIS) CPS fixation system in a pilot series.

Methods: Between January and July 2023, we treated a cohort of ten patients using a new cervical MIS platform. Forty pedicle screws were inserted percutaneously in the c-spine using intra-operative computed tomography (CT) guided navigation and retrospectively analysed for accuracy using a modified Gertzbein & Robbins (G&R) classification. Adverse events and other patient-related data were also documented.

Results: Ninety percent of all screws were placed accurately (80% on perfect trajectory, 10% showed minor perforations). Another 10% (four screws) caused pedicle wall breaches between 2 and 4 mm, but were not revised, since misplacement was not associated with neurological deficit or inferior biomechanics. One patient experienced neurological deterioration, but not associated with screw misplacement. The transverse foramen was breached twice, however not endangering the vertebral arteries.

Conclusions: In this pilot series MIS CPS placement yielded accurate placement rates comparable to open surgical approaches reported in the literature. Hence, MIS CPS placement appears to be a feasible and safe procedure in selected cases.
