磁性共价有机骨架材料富集和检测典型有机污染物的研究进展

Liu-Shan Jiang, Qing-Xiang Zhou
{"title":"磁性共价有机骨架材料富集和检测典型有机污染物的研究进展","authors":"Liu-Shan Jiang, Qing-Xiang Zhou","doi":"10.3724/SP.J.1123.2024.07020","DOIUrl":null,"url":null,"abstract":"<p><p>Trace contaminants are toxic and their widespread presence in the environment potentially threatens human health. The levels of these pollutants are often difficult to determine directly using instruments owing to the complexities of environment matrices. Hence, pretreatment steps, such as sample purification and concentration, are key along with various processes that enhance the accuracy and sensitivity of the detection method. To date, researchers have successfully developed a variety of efficient and reliable sample-pretreatment techniques that are based on different principles. Among these, magnetic solid-phase extraction (MSPE) is a rapid and efficient sample-pretreatment technology that is based on the similar solid-phase-extraction (SPE) principle, which mainly enriches target analytes by exploiting their interactions with functional groups on the surfaces of magnetic materials, thereby achieving rapid separation when an external magnetic field is applied. MSPE has been a focus of attention in the environmental-sample-pretreatment, food-analysis, and other fields owing to advantages that include ease of operation, low cost, and high enrichment efficiency. The selection of the magnetic material is key to MSPE process because traditional magnetic materials exhibit certain functionality limitations. Accordingly, designing and synthesizing green and efficient functionalized magnetic materials have become a research focus in this field, with researchers having extensively explored multiple ways of preparing functionalized modified magnetic materials through the introduction of a variety of emerging materials, including metal-organic frameworks (MOFs), covalent organic frameworks (COFs), carbon nanotubes (CNTs), graphene oxide (GO), and other specific functional groups to modify magnetic materials and effectively expanded the applications scope of MSPE. Among these, COFs are porous crystalline materials consisting of light elements (C, N, H, O and B, etc.) linked through covalent bonds. COFs are mainly classified as imine COFs, boronic-acid COFs, triazine COFs, and ketenimine COFs according to bonding type. Moreover, it is worth mentioning that COFs can be synthesized from a number of monomers, and the functional groups exposed on the COF surface can also be used for further modification purposes. COFs are versatile and modifiable; consequently, they have attracted significant research attention, with a series of COF-functionalized magnetic materials having been designed and synthesized. The magnetic COFs (MCOFs) combine the advantages of COFs and magnetic materials. MCOFs are not only endowed with the large specific surface areas, high porosities, and good stabilities that are characteristic of COFs, but also exhibit the rapid separation and reusability characteristics of magnetic material, thereby quickly and efficiently enriching targets through hydrogen bonding, hydrophobicity, <i>π-π</i> stacking, and van der Waals forces, making them ideal sample-pretreatment materials. MCOFs have also been converted into more-versatile functional materials using post-modification strategies. Combining MCOFs with advanced analytical techniques, such as high performance liquid chromatography (HPLC) and gas chromatography-mass spectrometry (GC-MS) has effectively improved the limits of detection (LODs) for various analytes as well as method accuracy; these techniques have been widely used to enrich and detect trace pollutants. However, some material design and synthesis challenges remain and need to be overcome, despite the promising potential of MCOFs. Future research needs to focus on exploring novel synthetic strategies that reduce experimental costs and improve the functionalities of MCOFs while expanding their applicabilities to broader sample matrices. In this review, we first introduce and discuss the construction and functionalized designs of various MCOF composites, and then summarize their use in applications that include the enrichment and detection of pesticides, endocrine disruptors (EDCs), pharmaceuticals, and personal care products (PPCPs), and finally provide an outlook on future developmental prospects.</p>","PeriodicalId":101336,"journal":{"name":"Se pu = Chinese journal of chromatography","volume":"43 2","pages":"107-119"},"PeriodicalIF":0.0000,"publicationDate":"2025-02-01","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11758229/pdf/","citationCount":"0","resultStr":"{\"title\":\"[Recent progress in magnetic covalent organic framework materials for the enrichment and detection of typical organic pollutants].\",\"authors\":\"Liu-Shan Jiang, Qing-Xiang Zhou\",\"doi\":\"10.3724/SP.J.1123.2024.07020\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p><p>Trace contaminants are toxic and their widespread presence in the environment potentially threatens human health. The levels of these pollutants are often difficult to determine directly using instruments owing to the complexities of environment matrices. Hence, pretreatment steps, such as sample purification and concentration, are key along with various processes that enhance the accuracy and sensitivity of the detection method. To date, researchers have successfully developed a variety of efficient and reliable sample-pretreatment techniques that are based on different principles. Among these, magnetic solid-phase extraction (MSPE) is a rapid and efficient sample-pretreatment technology that is based on the similar solid-phase-extraction (SPE) principle, which mainly enriches target analytes by exploiting their interactions with functional groups on the surfaces of magnetic materials, thereby achieving rapid separation when an external magnetic field is applied. MSPE has been a focus of attention in the environmental-sample-pretreatment, food-analysis, and other fields owing to advantages that include ease of operation, low cost, and high enrichment efficiency. The selection of the magnetic material is key to MSPE process because traditional magnetic materials exhibit certain functionality limitations. Accordingly, designing and synthesizing green and efficient functionalized magnetic materials have become a research focus in this field, with researchers having extensively explored multiple ways of preparing functionalized modified magnetic materials through the introduction of a variety of emerging materials, including metal-organic frameworks (MOFs), covalent organic frameworks (COFs), carbon nanotubes (CNTs), graphene oxide (GO), and other specific functional groups to modify magnetic materials and effectively expanded the applications scope of MSPE. Among these, COFs are porous crystalline materials consisting of light elements (C, N, H, O and B, etc.) linked through covalent bonds. COFs are mainly classified as imine COFs, boronic-acid COFs, triazine COFs, and ketenimine COFs according to bonding type. Moreover, it is worth mentioning that COFs can be synthesized from a number of monomers, and the functional groups exposed on the COF surface can also be used for further modification purposes. COFs are versatile and modifiable; consequently, they have attracted significant research attention, with a series of COF-functionalized magnetic materials having been designed and synthesized. The magnetic COFs (MCOFs) combine the advantages of COFs and magnetic materials. MCOFs are not only endowed with the large specific surface areas, high porosities, and good stabilities that are characteristic of COFs, but also exhibit the rapid separation and reusability characteristics of magnetic material, thereby quickly and efficiently enriching targets through hydrogen bonding, hydrophobicity, <i>π-π</i> stacking, and van der Waals forces, making them ideal sample-pretreatment materials. MCOFs have also been converted into more-versatile functional materials using post-modification strategies. Combining MCOFs with advanced analytical techniques, such as high performance liquid chromatography (HPLC) and gas chromatography-mass spectrometry (GC-MS) has effectively improved the limits of detection (LODs) for various analytes as well as method accuracy; these techniques have been widely used to enrich and detect trace pollutants. However, some material design and synthesis challenges remain and need to be overcome, despite the promising potential of MCOFs. Future research needs to focus on exploring novel synthetic strategies that reduce experimental costs and improve the functionalities of MCOFs while expanding their applicabilities to broader sample matrices. In this review, we first introduce and discuss the construction and functionalized designs of various MCOF composites, and then summarize their use in applications that include the enrichment and detection of pesticides, endocrine disruptors (EDCs), pharmaceuticals, and personal care products (PPCPs), and finally provide an outlook on future developmental prospects.</p>\",\"PeriodicalId\":101336,\"journal\":{\"name\":\"Se pu = Chinese journal of chromatography\",\"volume\":\"43 2\",\"pages\":\"107-119\"},\"PeriodicalIF\":0.0000,\"publicationDate\":\"2025-02-01\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11758229/pdf/\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Se pu = Chinese journal of chromatography\",\"FirstCategoryId\":\"1085\",\"ListUrlMain\":\"https://doi.org/10.3724/SP.J.1123.2024.07020\",\"RegionNum\":0,\"RegionCategory\":null,\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"\",\"JCRName\":\"\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Se pu = Chinese journal of chromatography","FirstCategoryId":"1085","ListUrlMain":"https://doi.org/10.3724/SP.J.1123.2024.07020","RegionNum":0,"RegionCategory":null,"ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"","JCRName":"","Score":null,"Total":0}
引用次数: 0

摘要

微量污染物是有毒的,它们在环境中的广泛存在可能威胁人类健康。由于环境矩阵的复杂性,这些污染物的水平往往难以用仪器直接确定。因此,预处理步骤,如样品纯化和浓缩,以及提高检测方法的准确性和灵敏度的各种过程是关键。迄今为止,研究人员已经成功地开发了各种基于不同原理的高效可靠的样品预处理技术。其中,磁固相萃取(MSPE)是基于类似固相萃取(SPE)原理的一种快速高效的样品前处理技术,主要是利用目标分析物与磁性材料表面官能团的相互作用来富集目标分析物,从而在外加磁场作用下实现快速分离。MSPE具有操作简单、成本低、富集效率高等优点,已成为环境-样品-预处理、食品分析等领域的研究热点。磁性材料的选择是MSPE工艺的关键,因为传统的磁性材料具有一定的功能局限性。因此,设计和合成绿色高效的功能化磁性材料已成为该领域的研究热点,研究人员通过引入各种新兴材料,包括金属有机框架(MOFs)、共价有机框架(COFs)、碳纳米管(CNTs)、氧化石墨烯(GO)、等特定的官能团来修饰磁性材料,有效地扩大了MSPE的应用范围。其中,COFs是由C、N、H、O、B等轻元素通过共价键连接而成的多孔晶体材料。根据键合类型,COFs主要分为亚胺类COFs、硼酸类COFs、三嗪类COFs和酮胺类COFs。此外,值得一提的是,COFs可以由多种单体合成,暴露在COF表面的官能团也可以用于进一步改性。COFs是通用的和可修改的;因此,它们引起了广泛的研究关注,人们设计和合成了一系列cof功能化磁性材料。磁性COFs (MCOFs)结合了COFs和磁性材料的优点。MCOFs不仅具有比表面积大、孔隙率高、稳定性好等特点,而且具有磁性材料的快速分离和可重复使用特性,可通过氢键、疏水性、π-π堆积和范德华力等快速高效富集靶材,是理想的样品前处理材料。利用后改性策略,MCOFs也被转化为更多功能的功能材料。将MCOFs与高效液相色谱(HPLC)、气相色谱-质谱(GC-MS)等先进分析技术相结合,有效提高了各种分析物的检出限(lod)和方法的准确性;这些技术已广泛应用于痕量污染物的富集和检测。然而,尽管MCOFs具有很大的潜力,但仍存在一些材料设计和合成方面的挑战,需要克服这些挑战。未来的研究需要集中在探索新的合成策略,以降低实验成本,提高MCOFs的功能,同时扩大其适用于更广泛的样本矩阵。本文首先介绍和讨论了各种MCOF复合材料的结构和功能化设计,然后总结了它们在农药、内分泌干扰物(EDCs)、药物和个人护理用品(PPCPs)的富集和检测方面的应用,最后展望了未来的发展前景。
本文章由计算机程序翻译,如有差异,请以英文原文为准。

[Recent progress in magnetic covalent organic framework materials for the enrichment and detection of typical organic pollutants].

[Recent progress in magnetic covalent organic framework materials for the enrichment and detection of typical organic pollutants].

[Recent progress in magnetic covalent organic framework materials for the enrichment and detection of typical organic pollutants].

[Recent progress in magnetic covalent organic framework materials for the enrichment and detection of typical organic pollutants].

Trace contaminants are toxic and their widespread presence in the environment potentially threatens human health. The levels of these pollutants are often difficult to determine directly using instruments owing to the complexities of environment matrices. Hence, pretreatment steps, such as sample purification and concentration, are key along with various processes that enhance the accuracy and sensitivity of the detection method. To date, researchers have successfully developed a variety of efficient and reliable sample-pretreatment techniques that are based on different principles. Among these, magnetic solid-phase extraction (MSPE) is a rapid and efficient sample-pretreatment technology that is based on the similar solid-phase-extraction (SPE) principle, which mainly enriches target analytes by exploiting their interactions with functional groups on the surfaces of magnetic materials, thereby achieving rapid separation when an external magnetic field is applied. MSPE has been a focus of attention in the environmental-sample-pretreatment, food-analysis, and other fields owing to advantages that include ease of operation, low cost, and high enrichment efficiency. The selection of the magnetic material is key to MSPE process because traditional magnetic materials exhibit certain functionality limitations. Accordingly, designing and synthesizing green and efficient functionalized magnetic materials have become a research focus in this field, with researchers having extensively explored multiple ways of preparing functionalized modified magnetic materials through the introduction of a variety of emerging materials, including metal-organic frameworks (MOFs), covalent organic frameworks (COFs), carbon nanotubes (CNTs), graphene oxide (GO), and other specific functional groups to modify magnetic materials and effectively expanded the applications scope of MSPE. Among these, COFs are porous crystalline materials consisting of light elements (C, N, H, O and B, etc.) linked through covalent bonds. COFs are mainly classified as imine COFs, boronic-acid COFs, triazine COFs, and ketenimine COFs according to bonding type. Moreover, it is worth mentioning that COFs can be synthesized from a number of monomers, and the functional groups exposed on the COF surface can also be used for further modification purposes. COFs are versatile and modifiable; consequently, they have attracted significant research attention, with a series of COF-functionalized magnetic materials having been designed and synthesized. The magnetic COFs (MCOFs) combine the advantages of COFs and magnetic materials. MCOFs are not only endowed with the large specific surface areas, high porosities, and good stabilities that are characteristic of COFs, but also exhibit the rapid separation and reusability characteristics of magnetic material, thereby quickly and efficiently enriching targets through hydrogen bonding, hydrophobicity, π-π stacking, and van der Waals forces, making them ideal sample-pretreatment materials. MCOFs have also been converted into more-versatile functional materials using post-modification strategies. Combining MCOFs with advanced analytical techniques, such as high performance liquid chromatography (HPLC) and gas chromatography-mass spectrometry (GC-MS) has effectively improved the limits of detection (LODs) for various analytes as well as method accuracy; these techniques have been widely used to enrich and detect trace pollutants. However, some material design and synthesis challenges remain and need to be overcome, despite the promising potential of MCOFs. Future research needs to focus on exploring novel synthetic strategies that reduce experimental costs and improve the functionalities of MCOFs while expanding their applicabilities to broader sample matrices. In this review, we first introduce and discuss the construction and functionalized designs of various MCOF composites, and then summarize their use in applications that include the enrichment and detection of pesticides, endocrine disruptors (EDCs), pharmaceuticals, and personal care products (PPCPs), and finally provide an outlook on future developmental prospects.
