Jie Ren, Qichen Wang, Fuzhou Han, Wenbin Guo, Yi Cao, Songbin Li, Geping Li, Muhammad Ali and Jianan Hu
{"title":"揭示 p 型 (Bi, Sb)2Te3 合金富 Sb SPP 中纳米级团簇的晶体学和形成机制。","authors":"Jie Ren, Qichen Wang, Fuzhou Han, Wenbin Guo, Yi Cao, Songbin Li, Geping Li, Muhammad Ali and Jianan Hu","doi":"10.1039/D4CP01674B","DOIUrl":null,"url":null,"abstract":"<p >Considering that the crystallographic characteristics of the Sb-rich secondary phase particles (SPPs) greatly affect the thermoelectric properties of Bi<small><sub>2</sub></small>Te<small><sub>3</sub></small> based materials, it is of great significance to explore the mechanism behind the Sb-rich SPPs in the p-type (Bi, Sb)<small><sub>2</sub></small>Te<small><sub>3</sub></small> material. Here a conventional TEM technique was used to characterize the composition, size and distribution of Sb-rich SPPs in a spark plasma sintered p-type (Bi, Sb)<small><sub>2</sub></small>Te<small><sub>3</sub></small> alloy. The results indicated that two different morphologies of Sb-rich SPPs including elongated and circular Sb-rich SPPs were frequently observed. Combined with high-resolution transmission electron microscopy, this work provides atomic-scale evidence for the formation mechanism behind the Sb-rich SPPs in the (Bi, Sb)<small><sub>2</sub></small>Te<small><sub>3</sub></small> material.</p>","PeriodicalId":99,"journal":{"name":"Physical Chemistry Chemical Physics","volume":" 22","pages":" 16200-16206"},"PeriodicalIF":2.9000,"publicationDate":"2024-05-28","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":"{\"title\":\"Uncovering the crystallography and formation mechanism of nanoscale clusters in Sb-rich SPPs of a p-type (Bi, Sb)2Te3 alloy†\",\"authors\":\"Jie Ren, Qichen Wang, Fuzhou Han, Wenbin Guo, Yi Cao, Songbin Li, Geping Li, Muhammad Ali and Jianan Hu\",\"doi\":\"10.1039/D4CP01674B\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p >Considering that the crystallographic characteristics of the Sb-rich secondary phase particles (SPPs) greatly affect the thermoelectric properties of Bi<small><sub>2</sub></small>Te<small><sub>3</sub></small> based materials, it is of great significance to explore the mechanism behind the Sb-rich SPPs in the p-type (Bi, Sb)<small><sub>2</sub></small>Te<small><sub>3</sub></small> material. Here a conventional TEM technique was used to characterize the composition, size and distribution of Sb-rich SPPs in a spark plasma sintered p-type (Bi, Sb)<small><sub>2</sub></small>Te<small><sub>3</sub></small> alloy. The results indicated that two different morphologies of Sb-rich SPPs including elongated and circular Sb-rich SPPs were frequently observed. Combined with high-resolution transmission electron microscopy, this work provides atomic-scale evidence for the formation mechanism behind the Sb-rich SPPs in the (Bi, Sb)<small><sub>2</sub></small>Te<small><sub>3</sub></small> material.</p>\",\"PeriodicalId\":99,\"journal\":{\"name\":\"Physical Chemistry Chemical Physics\",\"volume\":\" 22\",\"pages\":\" 16200-16206\"},\"PeriodicalIF\":2.9000,\"publicationDate\":\"2024-05-28\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Physical Chemistry Chemical Physics\",\"FirstCategoryId\":\"92\",\"ListUrlMain\":\"https://pubs.rsc.org/en/content/articlelanding/2024/cp/d4cp01674b\",\"RegionNum\":3,\"RegionCategory\":\"化学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"\",\"PubModel\":\"\",\"JCR\":\"Q3\",\"JCRName\":\"CHEMISTRY, PHYSICAL\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Physical Chemistry Chemical Physics","FirstCategoryId":"92","ListUrlMain":"https://pubs.rsc.org/en/content/articlelanding/2024/cp/d4cp01674b","RegionNum":3,"RegionCategory":"化学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q3","JCRName":"CHEMISTRY, PHYSICAL","Score":null,"Total":0}
引用次数: 0
摘要
考虑到富含锑的次生相颗粒（SPPs）的晶体学特征会极大地影响基于 Bi2Te3 材料的热电性能，因此探索 p 型（Bi, Sb）2Te3 材料中富含锑的次生相颗粒背后的机理具有重要意义。本文采用传统的 TEM 技术来表征火花等离子烧结 p 型 (Bi, Sb)2Te3 合金中富 Sb SPPs 的组成、尺寸和分布。结果表明，富Sb SPPs经常出现两种不同的形态，包括拉长的富Sb SPPs和圆形的富Sb SPPs。结合高分辨率透射电子显微镜，这项研究为（Bi，Sb）2Te3 材料中富硒 SPP 的形成机制提供了原子尺度的证据。
Uncovering the crystallography and formation mechanism of nanoscale clusters in Sb-rich SPPs of a p-type (Bi, Sb)2Te3 alloy†
Considering that the crystallographic characteristics of the Sb-rich secondary phase particles (SPPs) greatly affect the thermoelectric properties of Bi2Te3 based materials, it is of great significance to explore the mechanism behind the Sb-rich SPPs in the p-type (Bi, Sb)2Te3 material. Here a conventional TEM technique was used to characterize the composition, size and distribution of Sb-rich SPPs in a spark plasma sintered p-type (Bi, Sb)2Te3 alloy. The results indicated that two different morphologies of Sb-rich SPPs including elongated and circular Sb-rich SPPs were frequently observed. Combined with high-resolution transmission electron microscopy, this work provides atomic-scale evidence for the formation mechanism behind the Sb-rich SPPs in the (Bi, Sb)2Te3 material.
