Florian Scheible, Raphael Lamprecht, Casey Schaan, Reinhard Veltrup, Marion Semmler, Alexander Sutor
{"title":"What kind of phonation causes the strongest vocal fold collision? - A hemi-larynx phonation contact pressure study.","authors":"Florian Scheible, Raphael Lamprecht, Casey Schaan, Reinhard Veltrup, Marion Semmler, Alexander Sutor","doi":"10.1515/teme-2023-0002","DOIUrl":null,"url":null,"abstract":"<p><p>This paper presents a measurement setup which is able to measure the distribution of small scale pressure on an area of 15.2 mm × 30.4 mm with a sample rate up to 1.2 kHz. It was used to investigate the contact pressures of vocal folds during phonation. This was performed in ex vivo experiments of 11 porcine larynges. The contact pressure at the medial surface and other phonation parameters, as the glottal resistance and the closing velocity of the vocal fold, were measured at different adduction and elongation levels and air flow rates. A statistical analysis was carried out. It could be shown that the contact pressure rises, when the vocal fold is manipulated or when the flow rate is increased.</p>","PeriodicalId":56086,"journal":{"name":"Tm-Technisches Messen","volume":null,"pages":null},"PeriodicalIF":0.8000,"publicationDate":"2023-06-21","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC10995662/pdf/","citationCount":"0","resultStr":null,"platform":"Semanticscholar","paperid":null,"PeriodicalName":"Tm-Technisches Messen","FirstCategoryId":"5","ListUrlMain":"https://doi.org/10.1515/teme-2023-0002","RegionNum":4,"RegionCategory":"工程技术","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"2024/3/1 0:00:00","PubModel":"eCollection","JCR":"Q4","JCRName":"INSTRUMENTS & INSTRUMENTATION","Score":null,"Total":0}
引用次数: 0
Abstract
This paper presents a measurement setup which is able to measure the distribution of small scale pressure on an area of 15.2 mm × 30.4 mm with a sample rate up to 1.2 kHz. It was used to investigate the contact pressures of vocal folds during phonation. This was performed in ex vivo experiments of 11 porcine larynges. The contact pressure at the medial surface and other phonation parameters, as the glottal resistance and the closing velocity of the vocal fold, were measured at different adduction and elongation levels and air flow rates. A statistical analysis was carried out. It could be shown that the contact pressure rises, when the vocal fold is manipulated or when the flow rate is increased.
期刊介绍:
The journal promotes dialogue between the developers of application-oriented sensors, measurement systems, and measurement methods and the manufacturers and measurement technologists who use them.
Topics
The manufacture and characteristics of new sensors for measurement technology in the industrial sector
New measurement methods
Hardware and software based processing and analysis of measurement signals to obtain measurement values
The outcomes of employing new measurement systems and methods.
