Comparative Analysis of the Structure and Properties of Alumina Ceramics Obtained by Conventional Pressureless Sintering and Spark Plasma Sintering

IF 0.3 Q4 MATERIALS SCIENCE, MULTIDISCIPLINARY

Inorganic Materials: Applied Research Pub Date : 2025-07-15 DOI:10.1134/S2075113325700492

M. S. Boldin, D. A. Tikhonova, A. D. Borkova, S. I. Udachin, E. A. Lantsev, A. V. Voronin, A. A. Murashov, O. A. Belkin, A. V. Nokhrin, V. N. Chuvil’deev

{"title":"Comparative Analysis of the Structure and Properties of Alumina Ceramics Obtained by Conventional Pressureless Sintering and Spark Plasma Sintering","authors":"M. S. Boldin, D. A. Tikhonova, A. D. Borkova, S. I. Udachin, E. A. Lantsev, A. V. Voronin, A. A. Murashov, O. A. Belkin, A. V. Nokhrin, V. N. Chuvil’deev","doi":"10.1134/S2075113325700492","DOIUrl":null,"url":null,"abstract":"The effect of the initial size of alumina particles on the density, microstructure, hardness, and fracture toughness of ceramics obtained by conventional and spark plasma sintering (SPS) has been studied. We studied ceramics obtained from commercial Al2O3 powders with an initial particle size of 40 to 50 nm, 0.2 μm, and 1 μm and domestic fine powders with an initial particle size of 0.2 to 3 mm, and Al2O3 + 0.25 vol % MgO and Al2O3 + 10 vol % ZrO2. It is shown that the density of alumina ceramics nonmonotonically depends on the initial size of Al2O3 powder particles. It has been established that an increase in the grain size leads to a nonmonotonic change in the hardness of alumina ceramics. It has been established that the addition of 0.25 vol % MgO accelerates the sintering of alumina. The addition of 10 vol % ZrO2 makes it possible to provide an optimal combination of hardness and fracture toughness. It is shown that fine-grained ceramics obtained by the SPS method have a higher hardness. It has been suggested that SPS of submicron alumina powders with an amorphous layer on the surface, additionally stabilized by zirconia particles, is promising for further increasing the hardness of alumina ceramics.","PeriodicalId":586,"journal":{"name":"Inorganic Materials: Applied Research","volume":"16 3","pages":"649 - 661"},"PeriodicalIF":0.3000,"publicationDate":"2025-07-15","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"","citationCount":"0","resultStr":null,"platform":"Semanticscholar","paperid":null,"PeriodicalName":"Inorganic Materials: Applied Research","FirstCategoryId":"1085","ListUrlMain":"https://link.springer.com/article/10.1134/S2075113325700492","RegionNum":0,"RegionCategory":null,"ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"","PubModel":"","JCR":"Q4","JCRName":"MATERIALS SCIENCE, MULTIDISCIPLINARY","Score":null,"Total":0}

引用次数: 0

Abstract

The effect of the initial size of alumina particles on the density, microstructure, hardness, and fracture toughness of ceramics obtained by conventional and spark plasma sintering (SPS) has been studied. We studied ceramics obtained from commercial Al₂O₃ powders with an initial particle size of 40 to 50 nm, 0.2 μm, and 1 μm and domestic fine powders with an initial particle size of 0.2 to 3 mm, and Al₂O₃ + 0.25 vol % MgO and Al₂O₃ + 10 vol % ZrO₂. It is shown that the density of alumina ceramics nonmonotonically depends on the initial size of Al₂O₃ powder particles. It has been established that an increase in the grain size leads to a nonmonotonic change in the hardness of alumina ceramics. It has been established that the addition of 0.25 vol % MgO accelerates the sintering of alumina. The addition of 10 vol % ZrO₂ makes it possible to provide an optimal combination of hardness and fracture toughness. It is shown that fine-grained ceramics obtained by the SPS method have a higher hardness. It has been suggested that SPS of submicron alumina powders with an amorphous layer on the surface, additionally stabilized by zirconia particles, is promising for further increasing the hardness of alumina ceramics.

Abstract Image

查看原文本刊更多论文

传统无压烧结与放电等离子烧结氧化铝陶瓷的结构与性能比较分析

研究了氧化铝颗粒初始尺寸对传统和放电等离子烧结陶瓷的密度、显微组织、硬度和断裂韧性的影响。我们研究了初始粒径为40 ~ 50nm、0.2 μm和1 μm的商用Al2O3粉末和初始粒径为0.2 ~ 3mm、Al2O3 + 0.25 vol % MgO和Al2O3 + 10 vol % ZrO2的国产细粉制备的陶瓷。结果表明，氧化铝陶瓷的密度与Al2O3粉末颗粒的初始尺寸呈非单调关系。晶粒尺寸的增大导致氧化铝陶瓷硬度的非单调变化。结果表明，添加0.25%体积分数的MgO能加速氧化铝的烧结。添加10 vol % ZrO2可以提供硬度和断裂韧性的最佳组合。结果表明，SPS法制备的细晶陶瓷具有较高的硬度。研究结果表明，表面有非晶层的亚微米氧化铝粉末，外加氧化锆颗粒的稳定，有望进一步提高氧化铝陶瓷的硬度。

本文章由计算机程序翻译，如有差异，请以英文原文为准。

求助全文

约1分钟内获得全文求助全文
