Sca2Gri: Scalable Gridified Scatterplots

Abstract

Scatterplots are widely used in exploratory data analysis. Representing data points as glyphs is often crucial for in-depth investigation, but this can lead to significant overlap and visual clutter. Recent post-processing techniques address this issue, but their computational and/or visual scalability is generally limited to thousands of points and unable to effectively deal with large datasets in the order of millions. This paper introduces Sca²Gri (Scalable Gridified Scatterplots), a grid-based post-processing method designed for analysis scenarios where the number of data points substantially exceeds the number of glyphs that can be reasonably displayed. Sca²Gri enables interactive grid generation for large datasets, offering flexible user control of glyph size, maximum displacement for point to cell mapping, and scatterplot focus area. While Sca²Gri's computational complexity scales cubically with the number of cells (which is practically bound to thousands for legible glyph sizes), its complexity is linear with respect to the number of data points, making it highly scalable beyond millions of points.
