Understanding the Level of Integration in Existing Chemical Clusters: Case Study in the Port of Rotterdam.

Abstract

The petrochemical industry is composed of several interconnected processes that use fossil-based feedstock for producing chemicals. These processes are typically geographically clustered and often belong to different parties. Reducing the environmental impacts of the petrochemical industry is not straightforward due to, on the one hand, their reliance on fossil fuels for energy and as a feedstock and, on the other hand, the significant level of interconnected energy and material flows among processes. Current methods for analyzing changes to existing processes cannot capture the multitude and level of interactions. The goal of this paper is to create a model of a petrochemical cluster and analyze its physical characteristics and performance. This paper addresses this goal by developing an assessment method that combines process simulations, multiplex graph analysis, and key performance indicators. The method is applied to a case study based on the petrochemical cluster in the Port of Rotterdam, resulting in a uniquely highly detailed model of a petrochemical cluster. The network analysis results show that only some of the processes are very interconnected. From the performance analysis, it can be observed that the olefins process is the most carbon-intense and has high CO₂ emissions. Additionally, the results showed the importance of considering existing interconnections when assessing the current performance of existing petrochemical clusters or the performance due to future changes to chemical processes. For instance, some changes would occur to an industrial cluster by introducing alternative carbon sources, such as biomass or CO₂.

Supplementary information: The online version contains supplementary material available at 10.1007/s43615-024-00410-5.
