Automatic detection of adenoid hypertrophy on lateral nasopharyngeal radiographs of children based on deep learning.

Abstract

Background: Adenoid hypertrophy is a prevalent cause of upper airway obstruction in children, potentially leading to various otolaryngological complications and even systemic sequelae. The lateral nasopharyngeal radiograph is routinely employed for the diagnosis of adenoid hypertrophy. This study aimed to evaluate the accuracy and reliability of deep learning, using lateral nasopharyngeal radiographs, for the diagnosis of adenoid hypertrophy in pediatric patients.

Methods: In the retrospective study, the lateral nasopharyngeal X-ray images were collected from children receiving therapy in the Children's Hospital of Soochow University, the 983th Hospital of Joint Logistics Support Forces of Chinese PLA and the Suzhou Wujiang District Children's Hospital from January 2023 to November 2023. Five deep learning models, i.e., AlexNet, VGG16, Inception v3, ResNet50 and DenseNet121, were used for model training and validation. Receiver operating characteristic (ROC) curve analyses were used to evaluate the performance of each model. The best algorithm was compared with interpretations from three radiologists on 208 images in the internal validation group.

Results: The lateral nasopharyngeal X-ray images were collected from 1,188 children, including 705 males (59.3%) and 483 females (40.7%), aged 8 months to 13 years, with a mean age of 5.57±2.66 years. Among the five deep learning models, DenseNet-121 performed the best, with area under the curve (AUC) values of 0.892 and 0.872, with accuracy of 0.895 and 0.878, sensitivity of 0.870 and 0.838, and specificity of 0.913 and 0.906 in the internal and external validation groups, respectively. The diagnostic performance of DenseNet-121 was higher than that of the junior and mid-level radiologists (0.892 vs. 0.836, 0.892 vs. 0.869), close to the senior radiologist (0.892 vs. 0.901). However, Delong's test revealed no significant difference between DenseNet121 and each radiologist in the validation group (P=0.24, P=0.52, P=0.79).

Conclusions: All the five deep learning models in the study showed good performance for the diagnosis of adenoid hypertrophy, with DenseNet121 being the best, which was clinically relevant for the automatic identification of adenoid hypertrophy.
