使用多个 b 值评估乳腺病变的调整 DWI 词典与 BI-RADS 的诊断效用。

IF 2.5 3区 医学 Q2 RADIOLOGY, NUCLEAR MEDICINE & MEDICAL IMAGING
Magnetic Resonance in Medical Sciences Pub Date : 2024-10-01 Epub Date: 2023-05-26 DOI:10.2463/mrms.mp.2022-0056
Aika Okazawa, Mami Iima, Masako Kataoka, Ryosuke Okumura, Sachiko Takahara, Tomotaka Noda, Taro Nishi, Takayoshi Ishimori, Yuji Nakamoto
{"title":"使用多个 b 值评估乳腺病变的调整 DWI 词典与 BI-RADS 的诊断效用。","authors":"Aika Okazawa, Mami Iima, Masako Kataoka, Ryosuke Okumura, Sachiko Takahara, Tomotaka Noda, Taro Nishi, Takayoshi Ishimori, Yuji Nakamoto","doi":"10.2463/mrms.mp.2022-0056","DOIUrl":null,"url":null,"abstract":"<p><strong>Purpose: </strong>We aimed to investigate the diagnostic feasibility of an adjusted diffusion-weighted imaging (DWI) lexicon using multiple b values to assess breast lesions according to DWI-based breast imaging reporting and data system (BI-RADS).</p><p><strong>Methods: </strong>This Institutional Review Board (IRB)-approved prospective study included 127 patients with suspected breast cancer. Breast MRI was performed using a 3T scanner. Breast DW images were acquired using five b-values of 0, 200, 800, 1000, and 1500 s/mm<sup>2</sup> (5b-value DWI) on 3T MRI. Two readers independently assessed lesion characteristics and normal breast tissue using DWI alone (5b-value DWI and 2b-value DWI with b = 0 and 800 s/mm<sup>2</sup>) according to DWI-based BI-RADS and in combination with the standard dynamic contrast-enhanced images (combined MRI). Interobserver and intermethod agreements were assessed using kappa statistics. The specificity and sensitivity of lesion classification were evaluated.</p><p><strong>Results: </strong>Ninety-five breast lesions (39 malignant and 56 benign) were evaluated. Interobserver agreement for lesion assessment on 5b-value DWI was very good (k ≥ 0.82) for DWI-based BI-RADS categories, lesion type, and mass characteristics; good (k = 0.75) in breast composition; and moderate (k ≥ 0.44) in background parenchymal signal (BPS) and non-mass distribution. Intermethod agreement between assessments performed using either 5b-value DWI or combined MRI was good-to-moderate (k = 0.52-0.67) for lesion type; moderate (k = 0.49-0.59) for DWI-based BI-RADS category and mass characteristics; and fair (k = 0.25-0.40) for mass shape, BPS, and breast composition. The sensitivity and positive predictive values (PPVs) for 5b-value DWI were 79.5%, 84.6% and 60.8%, 61.1% for each reader, respectively; 74.4%, 74.4% and 63.0%, 61.7% for 2b-value DWI; and 97.4%, 97.4% and 73.1%, 76.0% for combined MRI. The specificity and negative predictive values (NPVs) were 64.3%, 62.5% and 81.8%, 85.4% for 5b-value DWI; 69.6%, 67.9% and 79.6%, 79.2% for 2b-value DWI; and 75.0%, 78.6% and 97.7%, 97.8% for combined MRI.</p><p><strong>Conclusion: </strong>Good observer agreement was observed in the 5b-value DWI. The 5b-value DWI based on multiple b-values might have the potential to complement the 2b-value DWI; however, their diagnostic performance tended to be inferior to that of combined MRI for the characterization of breast tumors.</p>","PeriodicalId":18119,"journal":{"name":"Magnetic Resonance in Medical Sciences","volume":" ","pages":"438-448"},"PeriodicalIF":2.5000,"publicationDate":"2024-10-01","publicationTypes":"Journal Article","fieldsOfStudy":null,"isOpenAccess":false,"openAccessPdf":"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11447468/pdf/","citationCount":"0","resultStr":"{\"title\":\"Diagnostic Utility of an Adjusted DWI Lexicon Using Multiple b-values to Evaluate Breast Lesions in Combination with BI-RADS.\",\"authors\":\"Aika Okazawa, Mami Iima, Masako Kataoka, Ryosuke Okumura, Sachiko Takahara, Tomotaka Noda, Taro Nishi, Takayoshi Ishimori, Yuji Nakamoto\",\"doi\":\"10.2463/mrms.mp.2022-0056\",\"DOIUrl\":null,\"url\":null,\"abstract\":\"<p><strong>Purpose: </strong>We aimed to investigate the diagnostic feasibility of an adjusted diffusion-weighted imaging (DWI) lexicon using multiple b values to assess breast lesions according to DWI-based breast imaging reporting and data system (BI-RADS).</p><p><strong>Methods: </strong>This Institutional Review Board (IRB)-approved prospective study included 127 patients with suspected breast cancer. Breast MRI was performed using a 3T scanner. Breast DW images were acquired using five b-values of 0, 200, 800, 1000, and 1500 s/mm<sup>2</sup> (5b-value DWI) on 3T MRI. Two readers independently assessed lesion characteristics and normal breast tissue using DWI alone (5b-value DWI and 2b-value DWI with b = 0 and 800 s/mm<sup>2</sup>) according to DWI-based BI-RADS and in combination with the standard dynamic contrast-enhanced images (combined MRI). Interobserver and intermethod agreements were assessed using kappa statistics. The specificity and sensitivity of lesion classification were evaluated.</p><p><strong>Results: </strong>Ninety-five breast lesions (39 malignant and 56 benign) were evaluated. Interobserver agreement for lesion assessment on 5b-value DWI was very good (k ≥ 0.82) for DWI-based BI-RADS categories, lesion type, and mass characteristics; good (k = 0.75) in breast composition; and moderate (k ≥ 0.44) in background parenchymal signal (BPS) and non-mass distribution. Intermethod agreement between assessments performed using either 5b-value DWI or combined MRI was good-to-moderate (k = 0.52-0.67) for lesion type; moderate (k = 0.49-0.59) for DWI-based BI-RADS category and mass characteristics; and fair (k = 0.25-0.40) for mass shape, BPS, and breast composition. The sensitivity and positive predictive values (PPVs) for 5b-value DWI were 79.5%, 84.6% and 60.8%, 61.1% for each reader, respectively; 74.4%, 74.4% and 63.0%, 61.7% for 2b-value DWI; and 97.4%, 97.4% and 73.1%, 76.0% for combined MRI. The specificity and negative predictive values (NPVs) were 64.3%, 62.5% and 81.8%, 85.4% for 5b-value DWI; 69.6%, 67.9% and 79.6%, 79.2% for 2b-value DWI; and 75.0%, 78.6% and 97.7%, 97.8% for combined MRI.</p><p><strong>Conclusion: </strong>Good observer agreement was observed in the 5b-value DWI. The 5b-value DWI based on multiple b-values might have the potential to complement the 2b-value DWI; however, their diagnostic performance tended to be inferior to that of combined MRI for the characterization of breast tumors.</p>\",\"PeriodicalId\":18119,\"journal\":{\"name\":\"Magnetic Resonance in Medical Sciences\",\"volume\":\" \",\"pages\":\"438-448\"},\"PeriodicalIF\":2.5000,\"publicationDate\":\"2024-10-01\",\"publicationTypes\":\"Journal Article\",\"fieldsOfStudy\":null,\"isOpenAccess\":false,\"openAccessPdf\":\"https://www.ncbi.nlm.nih.gov/pmc/articles/PMC11447468/pdf/\",\"citationCount\":\"0\",\"resultStr\":null,\"platform\":\"Semanticscholar\",\"paperid\":null,\"PeriodicalName\":\"Magnetic Resonance in Medical Sciences\",\"FirstCategoryId\":\"3\",\"ListUrlMain\":\"https://doi.org/10.2463/mrms.mp.2022-0056\",\"RegionNum\":3,\"RegionCategory\":\"医学\",\"ArticlePicture\":[],\"TitleCN\":null,\"AbstractTextCN\":null,\"PMCID\":null,\"EPubDate\":\"2023/5/26 0:00:00\",\"PubModel\":\"Epub\",\"JCR\":\"Q2\",\"JCRName\":\"RADIOLOGY, NUCLEAR MEDICINE & MEDICAL IMAGING\",\"Score\":null,\"Total\":0}","platform":"Semanticscholar","paperid":null,"PeriodicalName":"Magnetic Resonance in Medical Sciences","FirstCategoryId":"3","ListUrlMain":"https://doi.org/10.2463/mrms.mp.2022-0056","RegionNum":3,"RegionCategory":"医学","ArticlePicture":[],"TitleCN":null,"AbstractTextCN":null,"PMCID":null,"EPubDate":"2023/5/26 0:00:00","PubModel":"Epub","JCR":"Q2","JCRName":"RADIOLOGY, NUCLEAR MEDICINE & MEDICAL IMAGING","Score":null,"Total":0}
引用次数: 0

摘要

目的:我们旨在研究根据基于 DWI 的乳腺成像报告和数据系统(BI-RADS),使用多 b 值评估乳腺病变的调整后扩散加权成像(DWI)词典的诊断可行性:这项经机构审查委员会(IRB)批准的前瞻性研究纳入了127名疑似乳腺癌患者。使用 3T 扫描仪进行乳腺 MRI 扫描。在 3T 磁共振成像上使用 0、200、800、1000 和 1500 s/mm2 五个 b 值(5b 值 DWI)采集乳腺 DW 图像。两名阅读者根据基于 DWI 的 BI-RADS 并结合标准动态对比增强图像(联合 MRI),使用单独的 DWI(5b 值 DWI 和 b = 0 和 800 s/mm2 的 2b 值 DWI)独立评估病变特征和正常乳腺组织。使用卡帕统计评估了观察者之间和方法之间的一致性。对病变分类的特异性和敏感性进行了评估:结果:共评估了 95 例乳腺病变(39 例恶性,56 例良性)。在基于 DWI 的 BI-RADS 分类、病变类型和肿块特征方面,5b 值 DWI 病变评估的观察者间一致性非常好(k ≥ 0.82);在乳腺组成方面,一致性良好(k = 0.75);在背景实质信号(BPS)和非肿块分布方面,一致性中等(k ≥ 0.44)。在病变类型方面,使用 5b 值 DWI 或联合 MRI 进行的评估之间的方法间一致性为良好至中等(k = 0.52-0.67);在基于 DWI 的 BI-RADS 类别和肿块特征方面为中等(k = 0.49-0.59);在肿块形状、BPS 和乳腺组成方面为一般(k = 0.25-0.40)。每位读者对 5b 值 DWI 的敏感性和阳性预测值(PPV)分别为 79.5%、84.6% 和 60.8%、61.1%;对 2b 值 DWI 的敏感性和阳性预测值(PPV)分别为 74.4%、74.4% 和 63.0%、61.7%;对联合 MRI 的敏感性和阳性预测值(PPV)分别为 97.4%、97.4% 和 73.1%、76.0%。5b值DWI的特异性和阴性预测值(NPV)分别为64.3%、62.5%和81.8%、85.4%;2b值DWI的特异性和阴性预测值(NPV)分别为69.6%、67.9%和79.6%、79.2%;联合MRI的特异性和阴性预测值(NPV)分别为75.0%、78.6%和97.7%、97.8%:结论:在 5b 值 DWI 中观察到了良好的观察者一致性。基于多个 b 值的 5b 值 DWI 可能具有补充 2b 值 DWI 的潜力;但是,就乳腺肿瘤的特征描述而言,它们的诊断性能往往不如联合 MRI。
本文章由计算机程序翻译,如有差异,请以英文原文为准。
Diagnostic Utility of an Adjusted DWI Lexicon Using Multiple b-values to Evaluate Breast Lesions in Combination with BI-RADS.

Purpose: We aimed to investigate the diagnostic feasibility of an adjusted diffusion-weighted imaging (DWI) lexicon using multiple b values to assess breast lesions according to DWI-based breast imaging reporting and data system (BI-RADS).

Methods: This Institutional Review Board (IRB)-approved prospective study included 127 patients with suspected breast cancer. Breast MRI was performed using a 3T scanner. Breast DW images were acquired using five b-values of 0, 200, 800, 1000, and 1500 s/mm2 (5b-value DWI) on 3T MRI. Two readers independently assessed lesion characteristics and normal breast tissue using DWI alone (5b-value DWI and 2b-value DWI with b = 0 and 800 s/mm2) according to DWI-based BI-RADS and in combination with the standard dynamic contrast-enhanced images (combined MRI). Interobserver and intermethod agreements were assessed using kappa statistics. The specificity and sensitivity of lesion classification were evaluated.

Results: Ninety-five breast lesions (39 malignant and 56 benign) were evaluated. Interobserver agreement for lesion assessment on 5b-value DWI was very good (k ≥ 0.82) for DWI-based BI-RADS categories, lesion type, and mass characteristics; good (k = 0.75) in breast composition; and moderate (k ≥ 0.44) in background parenchymal signal (BPS) and non-mass distribution. Intermethod agreement between assessments performed using either 5b-value DWI or combined MRI was good-to-moderate (k = 0.52-0.67) for lesion type; moderate (k = 0.49-0.59) for DWI-based BI-RADS category and mass characteristics; and fair (k = 0.25-0.40) for mass shape, BPS, and breast composition. The sensitivity and positive predictive values (PPVs) for 5b-value DWI were 79.5%, 84.6% and 60.8%, 61.1% for each reader, respectively; 74.4%, 74.4% and 63.0%, 61.7% for 2b-value DWI; and 97.4%, 97.4% and 73.1%, 76.0% for combined MRI. The specificity and negative predictive values (NPVs) were 64.3%, 62.5% and 81.8%, 85.4% for 5b-value DWI; 69.6%, 67.9% and 79.6%, 79.2% for 2b-value DWI; and 75.0%, 78.6% and 97.7%, 97.8% for combined MRI.

Conclusion: Good observer agreement was observed in the 5b-value DWI. The 5b-value DWI based on multiple b-values might have the potential to complement the 2b-value DWI; however, their diagnostic performance tended to be inferior to that of combined MRI for the characterization of breast tumors.

求助全文
通过发布文献求助,成功后即可免费获取论文全文。 去求助
来源期刊
Magnetic Resonance in Medical Sciences
Magnetic Resonance in Medical Sciences RADIOLOGY, NUCLEAR MEDICINE & MEDICAL IMAGING-
CiteScore
5.80
自引率
20.00%
发文量
71
审稿时长
>12 weeks
期刊介绍: Magnetic Resonance in Medical Sciences (MRMS or Magn Reson Med Sci) is an international journal pursuing the publication of original articles contributing to the progress of magnetic resonance in the field of biomedical sciences including technical developments and clinical applications. MRMS is an official journal of the Japanese Society for Magnetic Resonance in Medicine (JSMRM).
×
